FRAME Spark Carbon HMX SL Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148 mm with 55 mm Chainline Lightest 120 mm frame 1870g (w/shock)
FOX 34 Float Factory Air / Kashima FIT4 3-Modes with low Speed adj. / Kabolt 15x110 mm axle / 44 mm offset Tapered steerer / Lockout / Reb. Adj. 130mm travel
FOX NUDE 5T Factory EVOL Trunnion SCOTT custom SHOCK w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Custom large Air volume / DPS / Kashima / Reb. Adj. Travel 120-80-Lockout / T165X45 mm
SRAM Eagle AXS Rocker Controller Shifters
SRAM XX1 Eagle AXS / 12 Speed Wireless Electronic Shift System REAR Derailleur
SRAM XX1 CASSETTE XG1299 / 10-52 T
CRANKS SRAM XX1 Eagle Carbon crankarm DUB / 55 mm CL / 32T
SRAM CN XX1 Eagle Chain
WHEELS Syncros Silverton 1.0S-30 6 Bolt F: 15x110 mm R: 12x148 mm 30 mm Tubeless ready Carbon rim 28H DT Swiss 240 Ratchet EXP 36 / XD Driver SRAM TyreWiz / Syncros SL Axle w/Removable Lever with 6 mm Allen T30 and T25 Tools
TIRES Schwalbe Wicked Will 29x2.4" EVO Super Race / TLE / 67EPI / Addix Speed Soft
HANDLEBAR Syncros Fraser iC SL DC Carbon 0° rise / back sweep 8° / mini Rise / 760 mm Syncros Pro lock-on grips
BRAKES Trickstuff Piccola HD Carbon 4 Piston Disc Trickstuff Dächle Ultra-Light / F; R 180mm
FOX Transfer Factory Dropper Post Kashima Seatpost 31.6 mm / S; M size 125mm/L; XL size 150mm
SADDLE Syncros Tofino Regular 1.0 Carbon rails
APPROXIMATE WEIGHT 10.8 kg
NOTICE:
Some components may change from the manufacturer without prior notice
