FRAME Genius Alloy 6061, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Marzocchi Z2 Air Rail FORK , 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 150mm travel
X- Fusion NUDE 5 RLX Trunnion SHOCK, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 150-100-Lockout / T185X55mm
SRAM NX Eagle 12 Speed REAR Derailleur
SRAM SX Eagle Trigger SHIFTER LEVERS
SCOTT TwinLoc 2 Technology REMOTE CONTROL , Suspension & Dropper Remote, 3 Suspension modes
SRAM SX Eagle DUB CRANKS , 55mm CL / 32T
SRAM SX-PG1210 / 11-50T CASSETTE
SRAM CN SX Eagle CHAIN
FRONT HUB F: Formula CL-811 / 15x110mm
REAR HUB R: Formula CL-148S / 12x148mm
HEADSET Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 ZS56/40 MTB
WHEELS Syncros X-30S / 32H / 30mm / Sleeve Joint
TIRES Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO
HANDLEBAR Syncros Hixon 2.0 Alloy 6061 DB, 12mm Rise / back sweep 8° / 780mm
POWER Syncros AM 2.0, Syncros Cable Integration System, 4° rise / 6061 Alloy / 31.8mm / 1 1/8"
BRAKES Shimano MT501 Disc
Syncros Duncan Dropper Post, 31.6mm / S size 130mm / M size 150mm / L & XLsize 170mm
SADDLE Syncros Tofino 2.5 Regular
APPROXIMATE WEIGHT 15.8 kg
NOTICE:
Some components may change from the manufacturer without prior notice
