FRAME Genius Carbon / IMP Technology / HMX /1x optimized BB92 / Carbon SMC Link / Carbon swingarm VLK Virtual 4 Link kinematic 27.5" (2.6; 2.8) and 29" (2.4; 2.6) tire compatible with Geo-BB adj. SW dropouts for Boost 12x148 mm TBC Trunnion
FORK FOX 36 Float Factory Air / Kashima FIT4 3-Modes with low Speed adj. / Kabolt 15x110 mm axle 44 mm offset / tapered steerer / Reb. Adj. / Lockout 150 mm travel
FOX NUDE TR EVOL Trunnion SCOTT custom SHOCK ABSORBER w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend custom Ramp Adjust with linear and progressive settings DPS / Kashima / Reb. Adj. Travel 150-100-Lockout / 185X55 mm
REMOTE CONTROL SCOTT TwinLoc TSP Technology Suspension-Seatpost Remote below Bar / 3 modes / integ. Grip clamp
SRAM Eagle AXS Rocker Controller Shifters
SRAM X01 Eagle AXS / 12 Speed Wireless Electronic Shift System
SRAM X01 XG1295 / 10-52 T CASSETTE
CRANKS SRAM X01 DUB Eagle Carbon crankarm QF 168 / 32T
SRAM CN XX1 Eagle Chain
BRAKES Shimano XT M8120 4 Piston Disc
WHEELS Syncros Revelstoke 1.5 6 Bolt F: 15x110 mm R: 12x148 mm 30 mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with Tool;
TIRES Maxxis Dissector / 2.6" / 60TPI Foldable Tubeless Ready / EXO 3C maxx Terra
HANDLEBAR Syncros Hixon iC SL Carbon 12 mm rise / 9° / 780 mm / Syncros Pro lock-on grips
POWER BRAKES Shimano XT M8120 4 Piston Disc
FOX Transfer Factory Dropper Post Kashima Seatpost 31.6 mm / S size 125 mm / M & L size 150 mm / XL size 175 mm
SADDLE Syncros Tofino 1.5 Regular Titanium rails
NOTICE:
Some components may change from the manufacturer without prior notice
