FRAME Aluminum, 133mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard, intube, 750 Wh
FORK SR Suntour Aion 36X, Air, 150mm suspension travel, Tapered, 44mm fork offset, 29x2.6 max wheelsize
Rock Shox Deluxe Select SHOCK
Sram NX Eagle Single Click Shifters
CRANKS AND CHANGES Shimano FC-EM600, 165 mm all sizes, Sram Eagle Transmission E-MTB chainring
Sram NX Eagle Shifter
Sram NX Eagle Chain
Sram CS PG1230 Eagle 11-50T CASSETTE
BRAKES Sram DB8 Stealth [F] 200mm rotor (Sram CenterLine, 4 pistons), [R] 200mm rotor (Sram CenterLine, 4 pistons)
Shimano EP801 MOTOR
BATTERY Trendpower Internal Battery TPS-C04-35SD Gen 2, 750 Wh, removable, Trendpower Battery holder
DISPLAY Shimano SC-EN600
CHARGER Trendpower EU Smart Charger
WHEELS Merida Expert TR II, Hubs [F] Novatec SL-ELITE D041SB-B15, [R] Novatec SL-TEAM D462SB-S3S-B12-11S
Maxxis Rekon 29x2.4 fold TR 3C EXO tires
MERIDA EXPERT eTR HANDLEBAR
MERIDA EXPERT eTR II POWER
MERIDA EXPERT TR II SEATPOST
MERIDA COMP SL SADDLE
LEZYNE E-BIKE POWER STVZO E115 FRONT LIGHT , reverse MERIDA Custom Mount
TAIL LIGHT USB REAR Light CG-214RG
NOTICE:
Some components may change from the manufacturer without prior notice
