FRAME Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 140mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount, Range Booster Ready
FORK Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel
X-Fusion NUDE Trunnion SHOCK , SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm
SRAM NX Eagle / 12 Speed Rear Derailleur
SRAM SX Eagle Single Click Shifters
REMOTE CONTROL SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 modes
CRANKS FSA CK-320 / 165mm / 34T
SRAM PG1210/11-50T CASSETTE
SRAM SX Eagle Chain
FRONT HUB F: Formula CL-811 / 15x110mm
REAR HUB R: Formula CL-148S / Boost 148x12mm
HEADSET Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8", OD 52/62mm / ID 44/56mm
WHEELS Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
TIRES Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
HANDLEBAR Syncros Hixon 2.0 Rise / Alloy 6061D.B., 20mm rise / 8° / 760mms
POWER Syncros FL2.0 / 6061 Alloy, L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SRAM DB8 4 Piston Disc Brakes
SEATPOST Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
ENGINE Bosch Performance CX, EU: 25kmh / INT: 20mph
PowerTube 625Wh Battery
Bosch Purion display
4A Charger
LIGHTS F: Bosch Light Cable pre-installed, R: Bosch Light Cable pre-installed
APPROXIMATE WEIGHT 24.3 kg
NOTICE:
Some components may change from the manufacturer without prior notice
