FRAME Alloy Frame / Virtual 4 link kinematic VLK 27.5" and 29" compatible / geo adj. / Boost 148x12mm 150mm travel / Bosch SmartSystem / Integr. removable Battery 1.5" Headtube Central Kickstand Mount Integr. Cable Bosch PowerMore Read, color black
FORK Marzocchi Z2 Air / eMTB+ Rail 3 / 3 modes / 15x110mm QR axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 150mm travel
SHOCK X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 150-100-Lockout / 185x55mm
SRAM NX Eagle / 12 Speed REAR Derailleur
SRAM SX Eagle Single Click SHIFTER LEVERS
REMOTE CONTROL SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 modes
CRANKS FSA CK-320 / 165mm / 34T
SRAM PG1210/11-50T CASSETTE
SRAM SX Eagle CHAIN
FRONT HUB Formula CL-811 / 15x110mm
REAR HUB Formula CL-148S / Boost 148x12mm
STEERING Acros / 1.5quot; ZS56 OD62 / BlockLock / integra. Wire
WHEELS Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
TIRES Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
HANDLEBAR Syncros Hixon 2.0 Rise / Alloy 6061D.B., 20mm rise / 8° / 760mms
POWER Syncros FL2.0 / 6061 Alloy, L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
BRAKES Shimano / BR-MT420 4 Piston
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
ENGINE Bosch Performance CX, EU: 25km/h / INT: 20mph
PowerTube 625Wh BATTERY
Bosch LED Remote Intuvia 100 SCREEN
CHARGER 4A Charger
F LIGHTS : Bosch Light Cable pre-installed, Famp;R
APPROXIMATE WEIGHT 24.4 kg (with tubes)
NOTICE:
Some components may change from the manufacturer without prior notice
