FRAME Carbon, 160mm suspension travel, 29x2.4 max. wheelsize, 148x12mm standard axle, fixed battery
Fox 36 Float Factory FORK
Fox Float X Factory SHOCK
SHIFTERS Sram AXS Pod Ultimate Controller
CRANKS AND CRANKS Sram XX Eagle E-MTB Crank 165mm, Sram XX Eagle Transmission E-MTB for BOSCH 34 teeth
CHANGE Sram XX Eagle Transmission AXS
Sram XX Eagle Transmission Flattop CHAIN
Sram XX Eagle Transmission, 10-52 teeth, 12 speed cassette
BRAKES Sram Maven Ultimate, 4 pistons, Sram HS2 [F]203mm, [R]200mm discs
Bosch Performance Line SX ENGINE , MERIDA Custom Cover casing
Bosch CompactTube 400 Wh integrated battery
DISPLAY Bosch Purion 400
CHARGER Bosch 4A Charger (220-240V)
WHEELS Rims: Part of wheelset -FSA SC30; 30mm inner rim width; coal; Tubeless ready (tubeless tape and valves included) Spokes: Part of wheelset Front Hub: Part of wheelset - FSA SC30; 110x15mm; 6-Bolt Rear Hub: Part of wheelset - FSA SC30; 148x12mm; 6-Bolt; SRAM XD with Merida Expert TR axle; including removable lever, 6/4mm allen key
TIRES [F] Maxxis Assegai 29x2.5, fold, TR EXO+ 3C MaxxGrip, [R] Maxxis Minion DHR II 29x2.4, fold, TR EXO+ 3C MaxxTerra
HANDLEBAR Race Face Era 780mm, XSHORT-SHORT:20mm rise, MID-LONG-XLONG:40mm rise
MERIDA EXPERT eTR II POWER
Fox Transfer Factory POST , 34.9mm diameter, 0mm setback
Proxim Nembo Triox saddle
TAIL LIGHT CG-404RG-BLK
NOTICE:
Some components may change from the manufacturer without prior notice
