FRAME Carbon, 160mm suspension travel, 29x2.6" max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh
FORK Fox 38 Factory eMTB+, Air, 170mm suspension travel, Tapered, 44mm fork offset, 29x2.6 max wheelsize
Fox Factory Float X2 SHOCK , 2 Pos Lever
SHIFT CONTROLS Sram AXS Pod Controller
CRANKS AND CHANGES Shimano FC-EM900, 165 mm all sizes, Sram XX Eagle Transmission E-MTB for Steps
CHANGE Sram XX Eagle Transmission AXS
Sram XX Eagle Transmission CHAIN
Sram XX Eagle Transmission CASSETTE , 10-52, 12 speed
BRAKES Sram Code Ultimate Stealth [F] 220mm rotor (Sram HS2, 4 pistons), [R] 200mm rotor (Sram HS2, 4 pistons)
Shimano EP801 MOTOR
BATTERY Trendpower Internal Battery 600 Wh TPS-C15-58SD, Shimano Gen 2, integrated, Trendpower Battery Fixed Fixation
DISPLAY Shimano SC-EM800
CHARGER Trendpower EU Smart Charger
DT Swiss HXC 1501 WHEELS
TIRES [F] Maxxis Assegai, [R] Maxxis Minion DHR II
MERIDA EXPERT eTR HANDLEBAR
MERIDA EXPERT eTR II POWER
MERIDA TEAM TR II SEATPOST
Proxim Nembo Triox saddle
LEZYNE E-BIKE POWER STVZO E115 FRONT LIGHT , reverse MERIDA Custom Mount
REAR LIGHT Lezyne LED Fempto USB rear STVZO
NOTICE:
Some components may change from the manufacturer without prior notice
