FRAME Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered head tube, internal cables, Motor Armor motor guard, angle-adjustable headset, adjustable Mino Link Geometry, adjustable lever ratio, 34.9mm seatpost, ABP, UDH, rack and fender mounts, Boost148, 120mm travel
FORK Size S: RockShox Recon Silver, Solo Air spring, Motion Control, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, fender mounts, 150mm travel; Sizes M, L, XL: RockShox Recon Silver, Solo Air spring, Motion Control, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, fender mounts, 130mm travel
RockShox Deluxe Select R SHOCK , 210x50 mm
Shimano U6000 shifters , 10 speed
FSA Bosch CK-220 crankset , 36T chainring, 165mm length
Shimano CUES U6000 GS Shifter
Shimano LG500 chain , 9/10/11 speeds
Shimano CUES LG300 CASSETTE , LINKGLIDE, 11-48, 10 speeds
BRAKES Tektro Gemini SL 4-piston hydraulic brake
Bosch Performance Line CX engine , 32 km/h maximum assistance (25 km/h maximum assistance in EU and APAC)
Bosch PowerTube 800 Wh battery , intelligent system
DISPLAY Bosch Purion 200
Bosch standard charger 2A, 230V, smart system
WHEELS Bontrager Line TLR 30, Tubeless Ready, Presta valve, 14g black stainless steel spokes; Size S: 28-hole; Sizes M, L, XL: 32-hole
TIRES Size S: Bontrager Gunnisson Pro XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40"; Sizes M, L, XL: Bontrager Gunnisson Pro XR, Tubeless Ready, dual-compound, aramid bead, 60 tpi, 29x2.40"
HANDLEBAR Bontrager Comp, alloy, 31.8 mm, rise 40 mm, width 780 mm
Bontrager Comp Stem , 31.8mm, Blendr Compatible, 7 Degree, 50mm Stem Length
SEATPOST Size S: Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length; Sizes M, L, XL: Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 450mm length
SADDLE Bontrager Verse P3, steel rails
FENDERS Trek 27.5" custom fenders
