Aluminum FRAME , 27.5x2.25 max. wheelsize, 135x9mm axle standard, external, max. 504 Wh
Sr Suntour NVX30 DS FORK , coil, 80mm suspension travel, 27.5x2.4" max wheelsize
Shimano Cues U4000 Shifters
CRANKS AND CHAINRINGS Merida Expert TK 165mm, Samox NWP203 38 teeth
Shimano Cues U4000 Derailleur
KMC XGlide Chain
Sunrace CSU9 CASSETTE , 11-42 teeth, 9 speed
Shimano MT-200 2-piston brakes
Shimano EP5 60Nm MOTOR
Shimano EN604 Battery , 418Wh
DISPLAY Shimano SC-EN500
Shimano EC-E6002 Charger
Merida Comp TK Wheels
COVERS Maxxis Crossmark II 27.5x2.25", wire, reflecting line
Merida Expert Handlebar
POWER Merida Expert CT, XS/S/M-90, L/XL-110
Merida Comp CC Seatpost
Merida Comp TK SADDLE
Herrmans H-Black MR4 E Front Light
Rear light Spanninga Commuter Glow XE integrated in Merida MIK HD carrier
NOTICE:
Some components may change from the manufacturer without prior notice
