FRAME Aluminum, 700x50C with max. mudguard, 135x9mm axle, internal
SR Suntour NEX E25 fork , coil spring, 63mm travel, 700x52C max
Shimano CUES U6000-11 Shifters
FSA CK-220 GEN3 E-Bike Forged Crankset , 165mm, all sizes, FSA Direct Mount Steel Megatooth 38 tooth chainring
Shimano CUES U6000 GS derailleur
Shimano LG500 Chain
Shimano LG400-11 cassette , 11-50 teeth, 11 speeds
Shimano MT-200 2-piston brakes , Shimano RT10 180/180 mm discs
Bosch Performance Line Motor
Bosch Powertube 750 750Wh BATTERY
Bosch Kiox 300 Display
Bosch 4A Charger
WHEELS Merida Comp TK rims, Shimano QC300 front and rear hubs
700C TIRES , Continental eContact Plus 622-50 wire tire with reflective strip
Merida Expert Handlebar
STEM Merida Expert, 65mm XS/S/M, 90mm L/XL
Merida Comp TR IV Seatpost
Merida Expert CT SADDLE
Herrmans H-Black MR4 E Front Light
Spanninga Commuter Glow XE rear light integrated into Merida MIK HD luggage rack
NOTICE:
Some components may change from the manufacturer without prior notice
