FRAME Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
FORK Marzocchi Bomber Z2 100 QR15x110 E-Bike Optimized
POWER OC1 35mm interface -6º
OC Mountain Control MC31 HANDLEBAR , Rise20, Width 800
BRAKES Magura MT30 Hydraulic Disc Easy Route Connection
Shimano Deore M5130 Link Glide GS Shadow Plus REAR Derailleur
Shimano Deore M5130 Link Glide LEVERS
Shimano CS-LG400 11-43t 10-Speed CASSETTE
KMC eGlide CHAIN
Shimano Steps EM600 CRANKSETS AND CHAINRINGS ; Alloy EP8 36t w/chainguard
Orbea OC1 25c Tubeless Ready WHEELS
Schwalbe G-ONE Allround TIRES , 29x2.25, Performance Line RaceGuard, TLE, Reflective
ALLOY POST 31.6 Offset 0
SADDLE Selle Royal Vivo 1216 DRN 160x249mm
BATTERY Orbea Internal 540Wh (Optional 252Wh Range Extender)
Shimano EP8 MOTOR
CHARGER Orbea 2.Generation eBike Smart charger 42V/2-4A
CURANA Apollo FENDER 65mm
REAR GRILL Orbea Kemen oversize Alloy Rear Carrier (Max:18Kg)
FRONT LIGHT Lezyne Ebike POWER STVZO PRO E115 with remote 310 lumens
TAIL LIGHT Lezyne FENDER STVZO Alert Technology 11Lumen
NOTICE:
Some components may change from the manufacturer without prior notice
