FRAME Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FOX 34 Float Performance Air Grip FORK , 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel
FOX NUDE 5T EVOL Trunnion SHOCK , SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 120-80-Lockout / T165x45mm
SRAM GX Eagle AXSTransmission 12 Speed REAR Derailleur , Wireless Electronic Shift System
SRAM GX Eagle AXS Rocker Controller Shifters
SCOTT TwinLoc 2 Technology REMOTE CONTROL , Suspension & Dropper Remote, 3 Suspension modes
SRAM GX Eagle Transmission DUB CRANKS , 55mm CL / 32T
SRAM GX Eagle XS 1275 / 10-52 T CASSETTE
SRAM CN GX Eagle Transmission CHAIN
HEADSET Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 ZS56/40 MTB
WHEELS Syncros Silverton 2.5-30 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
TIRES F: Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft, R: Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
HANDLEBAR Syncros Fraser 1.5 DC Alloy 7075 DB, mini Rise / back sweep 8° / 760mm.
POWER Syncros DC 1.5, Syncros Cable Integration System, 0° rise / 7050 Alloy / 31.8mm / 1 1/8"
SRAM DB8 4 Piston Disc Brakes
SEATPOST Syncros Duncan Dropper Post 1.5, 31.6mm / S size 125mm / M size 140mm / L size 150mm / XL size 150mm
SADDLE Syncros Tofino 2.0 Regular CRMO rails
APPROXIMATE WEIGHT 12.9 kg (Tubeless setup)
NOTICE:
Some components may change from the manufacturer without prior notice
