FRAME Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline, color green
FOX 34 Float Rhythm Air Grip FORK, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel
FOX NUDE 5T EVOL Trunnion SHOCK , SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 120-80-Lockout / T165X45mm
Shimano XT RD-M8100 SGS REAR DErailleur , Shadow Plus / 12 Speed
SHIFTER LEVERS Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp
SCOTT TwinLoc 2 Technology REMOTE CONTROL , Suspension & Dropper Remote, 3 Suspension modes
CRANKS Shimano SLX FC-M7120-1 / Hollowtech 2, 55mm CL / 32T
Shimano Deore CS-M6100-12/10-51T CASSETTE
Shimano Deore CN-M6100 CHAIN
FRONT HUB F: Formula CL-811 / 15x110mm
REAR HUB R: Formula CL-148M / 12x148mm / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
HEADSET Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 ZS56/40 MTB
WHEELS Syncros X-30SE / 32H / 30mm Tubeless ready
TIRES F: Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft, R: Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
HANDLEBAR Syncros Fraser 2.0 DC Alloy 6061 DB, mini Rise / back sweep 8° / 760mm
POWER Syncros DC 2.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
BRAKES Shimano Deore M6120 4 Piston Disc
Syncros Duncan Dropper Post 2.0, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
SADDLE Syncros Tofino 2.0 Regular CRMO rails
APPROXIMATE WEIGHT 13.5 kg
NOTICE:
Some components may change from the manufacturer without prior notice
