FRAME Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FOX 36 Float Performance Elite Air FIT4 FORK , 3-Modes with low Speed adj. / Kabolt 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout, 160mm travel
FOX NUDE 5T EVOL Trunnion SHOCK , SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm
SRAM GX Eagle AXS 12 Speed REAR DErailleur, Wireless Electronic Shift System
SRAM GX Eagle AXS Rocker Controller SHIFTER LEVERS
SCOTT TwinLoc 2 Technology REMOTE CONTROL , Suspension & Dropper Remote, 3 Suspension modes
SRAM GX Eagle DUB CRANKS , 55mm CL / 32T
SRAM XG1275/10-52T CASSETTE
SRAM CN GX Eagle CHAIN
HEADSET Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 ZS56/40 MTB
WHEELS Syncros Revelstoke 1.5 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
TIRES Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
HANDLEBAR Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm
BRAKES Shimano XT M8120 4 Piston Disc
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm
SADDLE Syncros Tofino 1.5 Regular Titanium rails
APPROXIMATE WEIGHT 14.1 kg
NOTICE:
Some components may change from the manufacturer without prior notice
