FRAME Orbea Vibe Top Bar Hydro 6061 Hydroform Aluminum 2021, ICR cable routing, Forged BB, 135x9 QR, Flat Mount disc, 700x45 maximun tire, 1" 1/2 semi head set, 41x86.5 Pressfit BB, carrier and fenders compatible
FORK Orbea Vibe carbon fork, full carbon, 1-1/5, 700x45 maximun tire, flat mount disc mount, Thrue Axle12x100mm, Long mudguards compatible.
POWER Alloy forged, -6º, ICR
HANDLEBAR Alloy 31.8mm 12mm Rise 700mm
BRAKES Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
Shimano XT M8100 SGS Shadow Plus REAR Derailleur
Shimano Deore M6100 LEVERS
CASSETTE Sun Race CSMZ80 11-51t 12-Speed Metalic E-bike
KMC X12 CHAIN
CRANKS AND CRANKS CR 0.1, Forged alloy, 42t, w/Chainguard
WHEELS Alloy, Tubeless, 700c, 21c, 32H
TIRES Kenda K1052 700x45C Reflective type TLR
TJA Alloy, 27.2 mm, Setback 0, for integrated light
Brooks Cambium C15 SADDLE 283x140
Mahle 36V/6.9A 248Wh ANT+ BATTERY
ENGINE Mahle motor hub X35 Plus
Mahle X35 CHARGER
FRONT LIGHT Front position light, on head tube, COB Led, On/Off, 60 Lumen, ECE50
TAIL LIGHT Lezyne FENDER STVZO seatpost mounting 11 lumens
NOTICE:
Some components may change from the manufacturer without prior notice
